1. Important Information

Keep these instructions in a safe place and pass them on to

possible future owners.

• Use device for room heating within enclosed rooms only.

• Repairs and corrective measures may only be carried out by

skilled technicians.

• Disconnect the power supply in the event of fault (pull out

the device plug or switch off the fuse).

• Do not use this device next to the bathtub, shower,

washbasin or swimming pool.

• The device carries the symbol shown on the right,

which indicates that the heating device must under

no circumstances be covered with any objects.

• Children or persons who are not capable of

operating the device safely must not operate the heating

device. Ensure that children do not play with the device.

• Caution! Potential dangers can arise when the device

switches on automatically, e.g. devices which have been

covered or blocked by objects since they were last used can

cause fire.

• Do not operate the heating device in rooms where highly

flammable substances are used (e.g. solvents, etc.).

• Do not lay the connecting cable across the device.

2. Technical Device Description

Heat output: 2000 W Degree of protection: IP21

Connection voltage: 1/N~, 230-240 V, 50 Hz

Dimensions in mm: (W x H x D) 230 x 278 x 158

3. Installation

Do not cover the heating device with any objects; fire hazard!

The fan heater may only be used as shown, i.e. on a horizontal,

even surface. Using it on deep pile carpets is not permitted.

Please use caution when installing it in front of flammable

objects. The power plug must always be accessible.

Observe the minimum clearances.

4. Electrical Connection

The voltage information on the type plate must match the local

mains voltage. Due to inadvertant resetting of the thermal cut-

out, this appliance must not be supplied through an external

switching device.

When the power cord of this device is damaged, it must be

replaced by a qualified person, in order to avoid risks.

5. Operation

Pressing the "Operating mode" button allows you to select the

operating mode you want from cold air/low heating level/high

heating level. The "Setpoint temperature" buttons allow you to

set the room temperature you want.

The ring-shaped LED on the front of the device lights up red in

heating mode and blue in cold air mode .

If the set setpoint temperature is just 1° C above the current

room temperature, the heater automatically switches to the low

heating level. All of the valid settings made using the buttons

are confirmed by an acoustic signal. The setting made last is

automatically saved.

Warning!

Depending on the size of the room, heat requirement and

thermostat setting, rooms may overheat if the heating is not

controlled. This can be dangerous for people who are not able

to leave the room as it gets too hot.

6. Protection Against Overheating

If the permissible temperature is exceeded, the fan heater

switches off automatically. When this happens, pull out the

plug and remove the cause (e.g. when the air grid is blocked or

covered). When the device has cooled sufficiently, it can be

started up again.

7. Faults

In the event of faults, please contact your electrical retailer. If

required, you can also address your queries to the service

hotline of Glen Dimplex Deutschland GmbH.

Tel.: +49 (0) 9221 709-564

Fax: +49 (0) 9221 709-589

To process your order, please state the device type as well as

its production number (E-Nr.) and manufacturing date (FD).

This information is listed on the type plate.

8. Cleaning

To clean the device, it must be disconnected from the mains

and allowed to cool down. Clean the outside of the unit using a

soft, damp cloth. Do not use scouring powder or furniture polish

as this may damage the surface. Dust which gathers inside the

device can be removed from the outside using a vacuum

cleaner.

9. Warranty

This product is supplied with a two-year warranty according to

our terms of guarantee.

10. Note on Disposal

Do not dispose of the unit with general household

waste. The device must be taken to a local waste

disposal plant.

GB

Operating Instructions

Fan Heater H 500 TSD

Glen Dimplex Deutschland GmbH

h500-en_ba 02/11/A

Am Goldenen Feld 18 www.dimplex.de

D-95326 Kulmbach [email protected]
