English | 7

Bosch Power Tools 1 609 92A 3L6 | (2.11.16)

Noise/Vibration Information

Sound emission values determined according to

EN 60745-2-2.

Typically the A-weighted noise levels of the product are:

Sound pressure level 100 dB(A); Sound power level

111 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

(triax vector sum) and uncertainty K

determined according to EN 60745-2-2:

Impact tightening of fasteners of the maximum capacity of the

tool: a

h

=18m/s

2

, K=1,5 m/s

2

The vibration level given in this information sheet has been

measured in accordance with a standardised test given in

EN 60745 and may be used to compare one tool with anoth-

er. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or insertion tools or is

poorly maintained, the vibration emission may differ. This

may significantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working

period.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work pat-

terns.

Only for EC countries:

Declaration of Conformity

We declare under our sole responsibility that the product de-

scribed under “Technical Data” is in conformity with all rele-

vant provisions of the directives 2009/125/EC (Regulation

1194/2012), 2011/65/EU, until 19 April 2016:

2004/108/EC, from 20 April 2016 on: 2014/30/EU,

2006/42/EC including their amendments and complies with

the following standards: EN 60745-1, EN 60745-2-2,

EN 50581.

Technical file (2006/42/EC) at:

Robert Bosch Power Tools GmbH, PT/ECS,

70538 Stuttgart, GERMANY

Robert Bosch Power Tools GmbH

70538 Stuttgart, GERMANY

Stuttgart, 01.01.2017

Assembly

Battery Charging

 Use only the battery chargers listed on the accessories

page. Only these battery chargers are matched to the lith-

ium-ion battery of your power tool.

Note: The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the

battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-

ducing its service life. Interrupting the charging procedure

does not damage the battery.

The lithium-ion battery is protected against deep discharging

by the “Electronic Cell Protection (ECP)”. When the battery is

empty, the machine is switched off by means of a protective

circuit: The inserted tool no longer rotates.

 Do not continue to press the On/Off switch after the

machine has been automatically switched off. The bat-

tery can be damaged.

Observe the notes for disposal.

Removing the battery

The battery 4 is equipped with two locking levels that should

prevent the battery from falling out when pushing the battery

unlocking button 5 unintentionally. As long as the battery is

inserted in the power tool, it is held in position by means of a

spring.

To remove the battery 4, press the unlocking button 5 and

pull out the battery toward the front. Do not exert any force.

Changing the Tool (see figure A)

 Before any work on the machine itself (e. g. mainte-

nance, tool change, etc.) as well as during transport

and storage, remove the battery from the power tool.

Permitted ambient temperature

– during charging

– during operation

**

and during

storage

°C

°C

0... +45

-20... +50

Recommended batteries

GBA 18V..

GBA 18V...W

Recommended chargers

AL 18..

GAL 3680

GAL 18...W**

Cordless Impact Screwdriver GDS 18V-EC

300 ABR

* depending on the battery pack being used

** Limited performance at temperatures <0 °C

***

only for wireless charging batteries

Henk Becker

Executive Vice President

Engineering

Helmut Heinzelmann

Head of Product Certification

PT/ECS

OBJ_BUCH-2707-002.book Page 7 Wednesday, November 2, 2016 11:08 AM
