English | 9

Bosch Power Tools 1 609 92A 3S9 | (15.5.18)

The vibration level given in this information sheet has been

measured in accordance with a standardised test given in

EN 60745 and may be used to compare one tool with anoth-

er. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or insertion tools or is

poorly maintained, the vibration emission may differ. This

may significantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working

period.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work pat-

terns.

Assembly

Mounting the Protective Devices

 Before any work on the machine itself, pull the mains

plug.

Auxiliary Handle

 Operate your machine only with the auxiliary handle 5.

Screw the auxiliary handle 5 on the right or left of the machine

head depending on the working method.

 Do not make any alterations to the auxiliary handle.

 Do not continue to use an auxiliary handle if it is dam-

aged.

Auxiliary plate

Mount the auxiliary plate 4 to provide a better protection from

the hot air from the ventilation slots of the power tool.

The auxiliary plate 4 is fastened together with the auxiliary

handle 5.

Mounting the Polishing Tools

 Before any work on the machine itself, pull the mains

plug.

Clean the adapter 6 or 7 and all parts to be mounted.

Screw the adapter 6 or 7 into the power tool.

– Hold the adapter on the power tool with the open-end

spanner 13.

– Base on the accessories size, screw the adapter 6 or 7

clockwise with the second open-end spanner 13.

See graphics page for the mounting sequence.

Stick pad

Screw the stick pad 8 clockwise onto adapter 6 or 7.

Mount the plane sponge pad 9 or the lamb’s wool pad 10 or

the corrugated sponge pad 11 on the stick pad 8.

Polishing plate with sponge pad

Screw the polishing plate with sponge pad 12 clockwise onto

adapter 6 or 7.

Dust/Chip Extraction

 Dust from materials such as lead-containing coatings,

some wood types, minerals and metal can be harmful to

one’s health. Touching or breathing-in the dust can cause

allergic reactions and/or lead to respiratory infections of

the user or bystanders.

Certain dust, such as oak or beech dust, is considered car-

cinogenic, especially in connection with wood-treatment

additives (chromate, wood preservative). Materials con-

taining asbestos may only be worked by specialists.

– Provide for good ventilation of the working place.

– It is recommended to wear a P2 filter-class respirator.

Observe the relevant regulations in your country for the

materials to be worked.

 Prevent dust accumulation at the workplace. Dust can

easily ignite.

Operation

Starting Operation

 Observe correct mains voltage! The voltage of the pow-

er source must agree with the voltage specified on the

nameplate of the machine. Power tools marked with

230 V can also be operated with 220 V.

 Products sold in AUS and NZ only: Use a residual current

device (RCD) with a rated residual current of 30 mA or

less.

Switching On and Off

To save energy, only switch the power tool on when using it.

To start the power tool, press the On/Off switch 3.

To lock the pressed On/Off switch 3, press the lock-on button

2.

To switch off the power tool, release the On/Off switch 3, or

when it is locked, briefly press the On/Off switch 3 and then

release it.

 Check polishing tools before using. The polishing tool

must be mounted properly and be able to move freely.

Carry out a test run for at least one minute with no load.

Do not use damaged, out-of-centre or vibrating polish-

ing tools. Damaged polishing tools can burst and cause in-

juries.

Speed preselection

The required speed can be preselected with the thumbwheel

1 (also while running).

The required speed depends on the material and the working

conditions and can be determined through practical testing.

GPO 950_1 609 92A 3S9.book Page 9 Tuesday, May 15, 2018 4:38 PM
