Mode d’emploi Bourgini 22.9062.00.00 Kitchen Chef Robot sur socle

Mode d’emploi

98

PARTS DESCRIPTION

(See drawing on page 2)

1. Drive shaft for attaching the beaters

2. Lock button for lifting the mixer head

3. Speed control

The speed switch is also the on/off button:

Position 0 = off

Position 1 to 8 = on

4. Stainless steel mixing bowl with handle

5. Dough hook (“beater”)

6. Mixing hook (“beater”)

7. Whisk (“beater”)

INTRODUCTION

• Kitchen Chef made with recycled material.

• Compact and easy to store.

• Powerful 1000 Watt motor.

• 8 speeds and a pulse function.

• Green LED lighting.

• Reaches all edges of the bowl thanks to the

double eccentric mixing movement.

• Tilt-back head and anti-slip feet.

• Included accessories: Stainless-steel mixer, cast

aluminium pastry hook, cast aluminium mixing

hook, stainless-steel mixing bowl with handle:

4.5 litres.

• All standard accessories supplied are dishwasher

safe.

BEFORE FIRST USE

• Remove all packaging material and any stickers

and dispose of them separately so that they can

be recycled.

• Clean the device according to the instructions in

the CLEANING AND MAINTENANCE chapter.

USE

• Place the mixer on a solid surface.

• Open the mixer head diagonally upwards by

turning the lock button (2).

• Place the bowl on the base by positioning

the lugs at the bottom of the bowl next to the

arrow on the base, and then turn the bowl

clockwise.

• Attach the desired “beater” to the drive

shaft by holding the slots on the beater shaft

against those on the drive shaft, pressing the

beater against the spring, and turning it anti-

clockwise until it is firmly locked in position.

• Put the ingredients into the bowl. Add the

ingredients into the bowl. Not more than 550

grams of dry food + 450 grams of water together.

• In the case of heavy dough, fill the bowl to a

maximum of 1/3.

• Turn the lock button and lift the mixer head.

Make sure that the mixer head clicks firmly

into place!

• Begin mixing at low speed to avoid splashing,

and increase the speed slowly as required.

• After mixing, reset the speed control to 0.

• Turn the lock button and lift the mixer head.

• Remove any large lumps of ingredients from

the beater using a spatula or blunt knife

• Press the beater and turn it clockwise until it

releases.

• Turn the bowl to the right until it can be

removed.

• With a plastic or wooden spatula pour or

scrape the ingredients from the bowl for

further processing.

MIX AND BLEND TABLE

Speed Processing Beater Ingredient

1-4 Kneading Dough

hook

Dough for

bread, pizza,

pasta

5-6 Blending Mixing

hook

Dough for

cakes, biscuits,

ice cream

7-8 Mixing Whisk Egg white,

cream

Pulse Short final

processing

Whisk Adding extra

ingredients

Mix continuously for no longer than 6 minutes and

let the mixer cool down for 10 minutes.

Always start at a low speed and steadily increase

speed as necessary.

IMPORTANT: SAFETY SWITCHES

This mixer has 2 safety switches:

1. Thermal protection for the motor.

This prevents overheating. If the mixer is used

too intensively the motor will switch itself off.

Let the mixer cool down for at least 10 minutes.

Note: if this does happen, unplug the power cord

for a few minutes so that the safety switch can

reset itself, and turn the speed control to 0.

2. Safety switch for the mixer head.

When the mixer head is tilted upwards, the

motor will turn off.

ADDITIONAL SAFETY INSTRUCTIONS

• Switch off the mixer and remove the plug from

the wall socket in the event of malfunction during

use, before cleaning the appliance, and after use.

• Do not put hot liquids or hot ingredients into the

mixer. Lukewarm liquids and ingredients may be

used in the mixer.

• Keep long hair, scarves, jewellery and loose

clothing away from the rotating beaters to

prevent them from getting caught up; this applies

equally to cutlery and other kitchen utensils.

• Also keep your hands out of the way of the

rotating beaters.

• If an object such as a spoon, knife, etc., falls into

the bowl during use, immediately turn the mixer

off and remove the object before continuing with

mixing.

EN EN

• Do not move the mixer while it is in use.

• Never use the mixer without supervision.

• Keep the vents free.

• With certain processes the beaters are heated

up by friction. Bear this in mind when removing

them.

CLEANING AND MAINTENANCE

• Ensure that the appliance is not plugged in.

• Clean the bowl and beaters by hand or in the

dishwasher after each use. The bowl and beaters

are dishwasher safe.

• Clean the remaining parts of the mixer with a

damp cloth and some detergent.

STORAGE

• First allow the device to cool down completely

and clean it as directed.

• Place the device in such a way that no damage

can occur.

• Do not place other items on the device that could

damage it.

WARRANTY CONDITIONS

• Warranty is provided for 2 years from the date

of purchase according to the proof of purchase,

which is also the warranty certificate.

• Please turn to your retailer to claim your warranty.

• No warranty for defects resulting from misuse,

improper disassembly, damage due to falls,

bumps, etc.

• These warranty conditions take priority over the

general terms and conditions.

• This warranty does not cover consequential

damages.

• Damage to the device due to sharp objects is not

covered by the warranty.

SERVICE

For questions about the use of the product and

available spare parts, please consult our website:

www.bourgini.com.

Scan the code with your phone to go to the website:

AVAILABLE SPARE PARTS

Description Item Part number

Mixing bowl with

handle

4 22.5031.90.03

Dough hook

Black coated

5 22.5031.90.01

Mixing hook

Black coated

6 22.5031.90.02

Whisk 7 22.5031.90.04

WASTE DISPOSAL

Only for EU countries:

Electrical appliances, accessories and their

packaging must be reused as much as possible

in an environmentally sound manner. Do not dispose

of these items together with your normal rubbish.

According to the European 2002/96/EG WEEE

Guideline on the disposal of old electric and

electronic appliances, the appliances that are no

longer used must be collected and recycled in an

environmentally sound manner.

DISCLAIMER

Changes reserved; specifications are subject to

change without stating grounds for doing so.
