3

2.Turn hotplate knob to , push and hold

ELECTRONIC IGNITOR button.

Cylinder Placement

Cylinder cannot be placed under or in the appliance. Cylinders

are to be placed to the side and rear of the applaince. Cylinders

are to be a maximum diameter of 310mm and maximum height

of 600mm.

Hose Requirements

Use only approved hose which is certified to appropriate EN

standard and does not exceed 1.5m length. For Finland, the

hose length shall not exceed 1.2m.

Safety Tips

Before each use, check to see if hoses are cut or worn. Make

sure hose is not kinked. Make sure that when connected hose

does not touch any warm surfaces. Replace damaged hoses

before using appliance. Replace hose as required by national

requirements.

 Before opening gas cylinder valve, check the regulator for

tightness.

 When appliance is not in use, turn off all control knobs and

gas.

 Use long-handled barbecue utensils and oven mitts to

avoid burns and splatters. Use protective gloves when

handling hot components.

 Maximum load for hotplate and side shelf is 4.5 Kg.

Cooking vessel minimum dia 200mm and maximum dia.

260 mm.

 The grease cup (if equipped) must be inserted into

appliance and emptied after each use. Do not remove

grease cup until appliance has completely cooled.

 Be very careful when you open the lid, since hot steam

may escape.

 Be very careful when children, the elderly, or pets are

nearby.

 If you notice grease or other hot material dripping from

appliance onto valve, hose or regulator, turn off gas supply

at once. Determine the cause, correct it, then clean and

inspect valve, hose, and regulator before continuing.

Perform a leak test.

 Do not store objects or materials inside the appliance cart

enclosure that would block the flow of combustion air to the

underside of either the control panel or the firebox bowl.

 DO NOT disconnect or change gas container within 3m of

an open flame or other ignition source.

1. Open lid. Turn on gas at cylinder.

2. Place match into match holder, light match and place next to

burner ports. (Holder maybe on left or right side.)

3. Push in and turn burner knob to for burner being lit. Be

sure burner lights and stays lit.

4. Light adjacent burners in sequence by pushing knobs in and

turning to .

• Do not lean over appliance while lighting.

Match Lighting

WARNING

Turn controls and gas cylinder off when not in use.

• Do not lean over appliance while lighting.

Ignitor Lighting

1. Turn gas burner control valves to .

2. Turn ON gas at cylinder.

3. Open lid during lighting.

4. To ignite, turn ignition burner knob to .

5. Push and hold ELECTRONIC IGNITION button.

6. If ignition does NOT occur in 5 seconds, turn the burner

controls , wait 5 minutes and repeat lighting procedure.

7. Light adjacent burners in sequence by pushing knobs in and

turning to . If ignitor does not work, follow match lighting

instructions.

Hotplate Ignitor Lighting

• Do not lean over appliance while lighting.

1.Open hotplate lid. Turn on gas at cylinder.

Hotplate Match Lighting

3.Turn hotplate knob to . Be sure burner lights and stays lit.

3.If hotplate does NOT light, turn knob to , wait 5 minutes,

then repeat lighting procedure.

1.Open hotplate lid. Turn on gas at cylinder.

2.Place lit match near burner.

Regulator Requirements

A regulator must be used with this appliance. Use only gas

regulator supplied with your barbeque. If a regulator is not

supplied then use only regulator certified according to

EN12864 or EN16129 (Flow rate max. 1.5 kg/h) and approved

for your country and gas specified in Technical Data.
