Mode d’emploi Goobay 44794 Adaptateur HDMI

Mode d’emploi

Goobay®

by Wentronic GmbH | Pillmanstraße 12

38112 Braunschweig | Germany

REV2021-11-15

V1.0rs

44793, 44794

Compact HDMI™/VGA adapter incl. audio

1 Safety instructions

The user manual is part of the product and contains important information for

correct use.

• Read the user manual completely and carefully before use.

The user manual must be available for uncertainties and passing the

product.

• Keep this user manual.

• Do not open the housing.

• Do not modify product and accessories.

• Do not short-circuit connectors and circuits.

A defective device may not be put into operation, but must be protected

against further use.

• Use product, product parts and accessories only in perfect condition.

• Avoid stresses such as heat and cold, moisture and direct sunlight, mic-

rowaves, vibrations and mechanical pressure.

• In case of questions, defects, mechanical damage, trouble and other

problems, non-recoverable by the documentation, contact your dealer or

producer.

• Do not repair defective products yourself, but contact the dealer or the

manufacturer.

Not meant for children. The product is not a toy!

• Secure packaging, small parts and insulation against accidental use.

2 Description and function

2.1 Product

This product is a compact adapter that converts HDMI™ signals into VGA and

audio signals.

○ HDCP compliant

○ No external power source and no software required

2.2 Scope of delivery

Compact HDMI™/VGA adapter incl. audio connection, audio cable,

User Manual

2.3 Operating Elements

1 VGA jack

2 Audio jack

3 HDMI™ jack

4 HDMI™ plug

5 Audio cable with 2x 3.5mm jack

2.4 Specications

Article number 44793 44794

Input

HDMI™ jack

5V=, 0,5 A

HDMI™ plug

5V=, 0,5 A

Output

VGA jack

Audio jack

Max. Resolution

1920 x 1080

(1080p Full HD) @ 60 Hz

1920 x 1080

(1080p Full HD), inkl.

720p, 1600 x 1201

Dimensions (LxWxH) 48,8 x 20,1 x 15,5

Weight 21 g 24 g

Transmission

direction

HDMI™ -> VGA / Audio

Audio cable

Connections 2x 3.5 mm jack plug

Cable Length 1.1 m

3 Intended use

We do not permit using the device in other ways like described in

chapter "Description and Function" or in the "Safety Instructions".

Use the product only in dry interior rooms. Not attending to these

regulations and safety instructions might cause fatal accidents, injuries, and

damages to persons and property.

4 Preparation

1. Check the scope of delivery for completeness and integrity.

2. Compare the specications of all used devices and ensure compatibility.

5 Connection and operation

1. Connect your devices as shown in the illustration.

2. Disconnect all plug connections after use.

No controls need to be used during operation.

6 Maintenance, Care, Storage and Transportation

The product is maintenance-free.

NOTICE! Material damage

• Only use a dry and soft cloth for cleaning.

• Do not use detergents or chemicals.

• Store the product out the reach of children and in a dry and dust-protec-

ted ambience when not in use.

• Store cool and dry.

• Keep and use the original packaging for transport.

7 Disposal instructions

7.1 Product

According to the European WEEE directive, electrical and electronic

equipment must not be disposed with consumers waste. Its compo-

nents must be recycled or disposed apart from each other. Otherwise

contaminative and hazardous substances can damage the health and

pollute the environment.

As a consumer, you are committed by law to dispose electrical and electronic

devices to the producer, the dealer, or public collecting points at the end of the

devices lifetime for free. Particulars are regulated in national right. The symbol

on the product, in the user manual, or at the packaging alludes to these terms.

With this kind of waste separation, application, and waste disposal of used

devices you achieve an important share to environmental protection.

WEEE No: 82898622

7.2 Packaging

Packaging can be disposed of free of charge at the suitable collection

points – paper belongs in paper bins, plastics belong in yellow sacks

and glass belongs in used glass bins.

DE4535302615620

8 EU Declaration of conformity

With the CE sign Goobay®, a registered trademark of the Wentronic

GmbH ensures, that the product is conformed to the basic European

standards and directives.

9 Symbols used

For indoor use only IEC 60417- 5957

Recycling

ISO 7001 - PI PF 066

- 2 -

Subject to change without notice.

User ManualEN
