Mode d’emploi Hudora 65408 Trampoline

Mode d’emploi

8/16

WARNING: Do not allow your fingers to touch the end of the panels in the

hingejoint areas while you are folding or unfolding the trampoline. If your

fingers get caught between the ends of the panels, pinching can cause seri-

ous injuries!

STEP 3

Push the safety padding (6) over the panel frame. Make sure that the holes in

the safety padding (6) are perfectly alinged with the screw connections of the

stands. See figure 3.

NOTE: Place the opening over the screw connector and repeat this step for

the screw connection on the opposite end of the trampoline.

STEP 4

Screw the eight legs (7) into the screw connectors on the panel frame. See

Figure 4. The safety padding (6) must be securely connected with the frame

before the trampoline may be used. The trampoline must be placed firmly on

the ground as shown in figure 5.

STEP 5

Place the trampoline into its normal position suitable for its used. Make sure

that the safety padding (6) covers the springs of the folding trampoline.

Stand on the trampoline to make sure that all eight legs are placed straight on

the ground. See figure 5.

DISMANTLING / FOLDING OF THE TRAMPOLINE

STEP 6

Unscrew the legs (7) from the threaded supports of the frame (see figure 6).

STEP 7

You should remove the safety cushion, prior to folding up the trampoline.

Place the trampoline with the top down on a hard-wearing floor. Position

yourself on the frame of the trampoline in such a way that your left foot is in

the middle of frame section 4 and right foot is in the middle of frame section

3. Release the safety bolt (10) from the trampoline frame. Hold frame section

1 with your left hand and frame section 2 with the right one, and now pull in

the two frame sections towards yourself (see figure 7).

STEP 8

Fold the trampoline in the middle (see figure 8).

STEP 9

Now fold the entire trampoline as shown in figure 9.

HOW TO USE THE TRAMPOLINE

1. If possible always use the middle of the jumping mat.

2. You can bounce on the trampoline to gently stimulate your circulation.

3. You can do low jumps at high frequency on the trampoline to increase your

endurance.

4. You can do higher jumps, running movements and fitness elements (e.g.

„jumping jack“, „stretched jump“) on the trampoline to improve your coor-

dination, general mobility and balance.

Please refer to the relevant literature for other exercises.

MAINTENANCE AND STORAGE

Use a dry or damp cloth only to clean the product; do not use special cleaning

agents! Check the product for damage or traces of wear and tear before and

after each use. Do not make any structural changes. For your own safety,

please use original spare parts only. These can be sourced from HUDORA. If

parts become damaged or if sharp edges or corners should develop, the

product may not be used any more. If in any doubt, please contact our ser-

vice team (http://www.hudora.de). Store the product in a safe place where it

is protected from the elements, cannot be damaged, and cannot injure any-

one.

Store the trampoline in a dark area and protect it from dust and sharp ob-

jects. Clean the cloth material with a brush. All other parts may be cleaned

with a damp cloth. Use the protective covers to protect windings from corro-

sion whenever the legs are not installed.

DISPOSAL ADVICE

At the end of the product’s life, please dispose of it at an appropriate collec-

tion point provided in your area. Local waste management companies will be

able to answer your questions on this.

SERVICE

We make every effort to deliver faultless products. If faults do arise however,

we put just as much effort into rectifying them. Therefore, you can find nu-

merous information on the product, replacement parts, solutions to prob-

lems and lost assembly manuals at http://www.hudora.de.
