Mode d’emploi iHealth PT3 Thermomètre

Mode d’emploi

Instruction For Use

(2) Measurement process

(1) Installing the product

(3) Power o

(4) Unit switching

(6) Replacing batteries

(5) Installing and replacing batteries

1

2

3

≤1.18in(3cm)

4 5

Expected use and scope of applications

Contraindications

This product mainly uses IR temperature sensing of the

forehead to measure human body temperature. Can be used

for babies, children, and adults. Babies and children should

not operate the thermometer on their own. Body temperature

readings for babies and children should be taken by an adult.

Reminder: Temperature readings may dier according to skin

tone and measurement distance.

Insert the 2 battery cells from the packaging box into the

battery compartment at the back of the device. The product

will start automatic inspection and a standby mode (if the

device indicates low battery power, then replace the

batteries to ensure ample power supply).

The patient is an intended operator. The patient can measure,

transmit data and change battery.

If no more measuring is required, simply let the device sit idle

for 8 seconds to power o automatically.

When switched ON for use, the thermometer will

automatically detect remaining battery capacity. If battery

capacity is low but adequate for measurements, the low

power symbol [ ] will be displayed with the measurement

results. However, if the battery capacity is too low for

measurements, the screen will display a single, ashing [ ]

icon and automatically switch OFF after 8 seconds. To

continue using the device, old batteries must be replaced.

1. Press down and hold the battery cover with the nger and

apply some force to slide the cover backwards to open the

battery compartment.

2. Remove the old batteries and install the new batteries.

3. Refer to the battery polarity symbols to orient the batteries

properly during installation. Make sure that the new

batteries are tightly inserted into the battery compartment

and make sure that the polarity is not reversed during

installation.

4. Return the battery cover to close the battery compartment.

Comply with relevant national laws and regulations when

disposing of the used batteries.

Do not dispose of batteries directly into the trash bag.

Remove the batteries if the device will not be used more

than one month.

Reminder: If you do not press and hold the measurement

button for 8 seconds to conrm the unit selected before the

screen switches o, the system will consider the switch as a

failure and retain the original unit for temperature

measurements.

1. When the device is powered OFF, press and hold the

measurement button for 8 seconds to enter unit switching

mode. Under this mode, both ℃ and °F should ash at the

same time.

2. Under this mode, press the measurement button to switch

to Fahrenheit or Celsius. The corresponding symbol of the

selected unit after switching will ash.

3. After selecting the unit, press and hold the measurement

button for 8 seconds to leave the unit switching mode.

Aim the thermometer probe at the center of the

forehead and keep the probe 1.18in (3cm) away from

the forehead (the optimal distance is about the width of

an adult’s index nger). Do not touch the forehead with

the probe.

Gently press the

measurement button

[ ] to start the

measurement.

The device will vibrate

once a reading is obtained.

The reading will be

displayed on the screen. If

the measurement is failed,

the device will not vibrate

the screen but display

[ ] instead.

A. Measurement distance is greater than

1.18in (3cm);

B. Environment temperature does not

meet measurement requirements or

there is an excessively large

temperature dierence;

C. Target temperature exceeds

measurement range.

Possible reasons for measurement errors include:

It is not recommended for people whose measuring part has

local lesions, such as inammation, trauma, postoperative,

etc.
