Mode d’emploi Lanaform New Tech Thermomètre

Mode d’emploi

EN EN

TECHNICAL DETAILS

• Accurate measurements without contact with the body.

• Body temperature or ambient temperature according to what is selected.

• °C or °F can be selected by the user.

• Data storage: memorises the last 10 measurements

• Automatic switch o

• LCD display with backlighting

INSTRUCTIONS

By way of an indication, here are two tables giving the average temperature of a human being according to the place where the measurement is taken

and according to age.

Comment: The temperature of the human body varies during the day. It may also be in uenced by a number of external factors: age, sex, type and

thickness of the skin…

TECHNICAL SPECIFICATION

Normal conditions of use

Display resolution 0.1°C (0.1°F)

Operating temperature 16 to 35°C (60.8 to 95°F)

Storage temperature -25 to 55°C (-13 to 131°F)

Humidity rate <85%

Power supply 3V DC (2 “AA” batteries not included)

Dimensions 134.5x44.8x31.7mm (LxWxH)

Weight 121g (with batteries)

Measuring range

In “Body” mode 10 to 50 °C (50 to 122°F)

In “Object/Surface” mode 0 to 100°C (32 to 212°F)

Accuracy in “Body” mode ±0.3°C (0.5°F) 22.0-40.0°C (71.6-104°F)

Accuracy in “Object/Surface” mode <=20°C, 1°C; >20°C, +-5%

Measuring distance ± 4 to 6 cm

Automatic switch o 1 min.

32

Thermometer « New Tech »

THERMOMETER  NEW TECH 

INSTRUCTION MANUAL

Thank you for purchasing the LANAFORM® “Thermometer « New Tech »”.

This infrared thermometer has been speci cally designed not just for taking body temperature but also for checking the temperature of a baby’s bottle, a bath,

or even the ambient temperature. Thanks to its ergonomic shape and its new technology, the “Thermometer « New Tech »” lets you take a temperature reading

without direct contact with the body, any object or surface, and at any time of the day.

TITLE AND DESCRIPTION OF THE SYMBOLS IN THE LEAFLET DESCRIBING THE PRODUCT:

Symbol de nition Identi cation Manufacturer’s information

Manufacturer’s details LANAFORM SA, B-4141 SPRIMONT

Batch number 001

A BF type device

Please note, please see the instructions. Please note, please consult the attached documents.

Please read these instructions before using the device.

Please also follow these instructions carefully while using the device.

Organisation noti ed

Waste electrical and

electronic equipment (WEEE)

PLEASE READ ALL THE INSTRUCTIONS PRIOR TO USING YOUR “THERMOMETER « NEW TECH »”,

IN PARTICULAR THESE FEW BASIC SAFETY INSTRUCTIONS:

• Always keep your “Thermometer « New Tech »” away from sources of heat such as stoves and radiators, etc.

• Do not use this appliance in a room where aerosol products (sprays) are used or in a room where oxygen is administered.

• Do not submerge the device in water.

• Do not drop the device and do not use it if it is damaged.

• This aspirator must be used when the ambient temperature is between 16°C and 35°C.

• Do not expose this thermometer to extreme temperature conditions, that is temperatures higher than 55°C or lower than -25°C.

• Do not use this device if the relative humidity of the room is greater than 85%.

• Do not use this device close to strong magnetic  elds, like for example those produced by cordless telephones or mobile phones.

• Accuracy of the temperature measurement can be a ected if the forehead is covered by hair, sweat, a hat or a scarf. In that case ensure that the

temperature is taken behind the ear lobe. (See the corresponding paragraph below).

• We recommend keeping the thermometer in the room for 10 minutes before using it.

• Select “Body” mode in order to take human body temperature. For all other measurements, select “Object/Surface” mode.

• The use of this thermometer does not replace a consultation with your doctor.

• In case of problems with your device, please contact your reseller.

• Do not try to repair the device yourself.

• This device was not designed for use by people, including children, with reduced physical, sensory or mental capabilities, or people lacking

experience or knowledge, unless they have had the bene t of prior supervision, advice and instruction in using the device from a person responsible

for their safety. Children should be supervised to ensure that they do not play with the appliance.

• Only use the “Thermometer « New Tech »” for the use for which it is intended as described in this manual.

• The “Thermometer « New Tech »” is pre-con gured before leaving the factory. There is no need to calibrate it therefore before  rst using it.

• The glass lens protector is the most fragile part of the“Thermometer « New Tech »”. Do not touch the glass of the infrared lens with your  ngers.

Normal temperatures according to the method of measurement

Method of measurement Temperature °C Temperature °F

Rectum 36.6 to 38 97.8 to 100.4

Mouth 35.5 to 37.5 95.9 to 99.5

Armpit 34.7 to 37.3 94.4 to 99.1

Ear 35.8 to 38 96.4 to 100.4

Normal temperatures according to age

Age Temp. °C Temp. °F

0 to 2 years 36.4 to 38.0 97.5 to 100.4

3 to 10 years 36.1 to 37.8 97.0 to 100.0

11 to 65 years 35.9 to 37.6 96.6 to 99.7

>65 years 35.8 to 37.5 964 to 99.5

2

6

4

8

9

1

5

3

7

2

6

4

1

5

3

DESCRIPTION OF THE DEVICE:

Main unit.

Holder

IR sensor

LCD screen

Mode selection

Memory function

Measurement button

Operating button

Battery cover

DESCRIPTION OF THE LCD SCREEN:

Body mode symbol

Surface or object mode symbol

Digital reading

Battery symbol

Temperature memory

Temperature scale °C (Celsius) / °F (Fahrenheit)

Version 01-01/09/2011

4

2

1

3

5 6

2

5

8

7

4

1

6

3

9

Lanaform Thermometer Handleid.indd 2-3 5/12/11 10:14
