a standard double pole switch that ensures complete

disconnection from the mains in category III overvoltage

conditions, in accordance with the installation rules. •

Warning! The power cable must be replaced by the

authorised technical support service or by a person with

similar qualifications.

● Please note! Before reconnecting the circuit to the

mains power supply, make sure that it is working correctly,

always check that the power cable is correctly installed.

Please note! Do not use with a programmer, timer,

separate remote control or any other device that activates

automatically.

RECOMMENDATIONS FOR USE

Recommendations for correct use in order to reduce the

impact on the environment: When cooking begins, the

device should be turned on at minimum speed, and left on

for a few minutes even after cooking is complete. Increase

the speed only if there is a large quantity of fumes and

steam, using the Booster function only in extreme cases.

To keep the odour reduction system running efficiently,

replace the carbon filter/s when necessary. To ensure the

high performance of the grease filter, clean it when

necessary. To improve efficiency and minimise noise, use

the maximum duct diameter indicated in this manual.

REGULATIONS

Equipment designed, tested and manufactured in

compliance with safety regulations: EN/IEC 60335-1; EN/

IEC 60335-2- 31, EN/IEC 62233. Performance: EN/IEC

61591; ISO 5167-1; ISO 5167-3; ISO 5168; EN/IEC 60704-

1; EN/IEC 60704-2-13;EN/IEC 60704-3; ISO 3741; EN

50564; IEC 62301. EMC: EN 55014-1; CISPR 14-1; EN

55014-2; CISPR 14-2; EN/IEC 61000-3-2; EN/IEC 61000-

3-3.

2. USE

The extraction system can be used in the duct-out version

with external evacuation, or in the recirculating version with

filtering and internal recirculation.

●

Duct-Out Version:

Vapours are evacuated outside through an exhaust pipe

attached to the connecting flange.

CAUTION! If the product features one or more carbon

filters, they must be removed.

Connect the product to wall-mounted exhaust pipes and

holes with a diameter equivalent to the air outlet

(connecting flange).

The use of pipes and outlet holes in the wall with a smaller

diameter will reduce the extraction performance and

drastically increase the noise level.

All responsibility in this regard is therefore denied.

• Use a ducting pipe with the shortest length necessary.

• Use a ducting pipe with the least number of bends

possible (maximum bend angle: 90°).

• Avoid drastic changes in the ducting pipe diameter.

●

Recirculating Version:

The suctioned air will be degreased and deodorised before

it is sent back into the room. To use the product in this

version, it is necessary to install an additional activated

carbon filter system.

ASSEMBLY BEFORE INSTALLATION

• Check that the product is the right size for the installation

area.

• Remove the activated carbon filter(s) if supplied (see also

relevant paragraph).

• It(they) must be reinstalled if the product is used in the

filter version.

• If there are panels and/or walls and/or wall units on the

sides, make sure that there is enough space to install the

product and that it is always possible to access the control

panel easily.

• Do not make any modifications to the device or its

mounting bracket on the wall!

• Ask a professional to fix the hood to the wall.

• The wall on which the hood will be fixed must be in good

condition and must not show any damage (cracks,

subsidence, humidity, etc.). It must also be strong enough

to support the weight of the hood.

• Do not drill a hole close to old holes, even filled ones.

• It is essential to consult a building professional to use the

anchoring system (screws, dowels, etc.) appropriate to the

material that makes up your wall, as well as to the weight of

the appliance. Respect the diameter of the fixing screws

indicated in this manual.

Note: The fixing screws and dowels supplied with the

product can only be used if they are suitable for your wall

type. If the screws and dowels provided are not suitable for

the type of your wall, it is essential to use an appropriate

system recommended by the professional installer.

• The holes intended for fixing the appliance or its mounting

bracket to the wall must not be modified.

• The wall must be drilled using a drill of the correct size for

the anchoring system.

• Regularly check the fixing points of the appliance on the

wall. Tighten them if necessary.

3. OPERATION

T1 T5

T2

T3

T4

T1= Motor OFF

T2= 1st speed

T3= 2nd speed

T4= 3rd speed

T5= Lights ON/OFF.
