5. FUNCTIONS AND OPERATION
* Note: the right compartment is on the side where the compressor is.
• Power supply: Connect to DC 12V/24V or AC 100~240V (using dedicated adapter)
• Display Screen Initialization: When the cool box is switched on the buzzer will make a long beep, and
the display will be on for two seconds then enter the standby mode.
• Power On/O: Press to switch ON, long press for three seconds to switch OFF.
• Temperature Setting: Under the running state, long press and at the same time for three seconds
to switch ON/OFF the left compartment, long press and at the same time for three seconds to
switch ON/OFF the right compartment. Two compartments cannot be switched off at the same time.
When both left and right compartments are set in running state, press or to enter left compartment
temperature setting, press to increase temperature, press to decrease temperature, and press to
switch between left or right compartment. The setting will be saved after stop operating for four seconds
(Note: the temperature displayed is the current temperature of the compartments, it will take a while to
reach the set temperature.)
Temperature setting range: -20~20°C (-4~68°F)
• Cooling Mode: Under the running state, press to switch to MAX (fast cooling) and ECO (Energy saving
Mode). (*Factory setting is MAX.)
• Battery Protection Mode: under the running state, long press for three seconds until screen flashes,
then press again to select protection mode H (High), M (Medium) and L (Low).
(*Factory setting is H).
VOLTAGE REFERENCE:
* the voltage is a theoretical value, there may be a deviation in different scenarios.
* H should be set when the product is connected to car power, and M or L should be set when it is
connected to a portable battery or other back-up battery.
• Temperature Unit Setting: switch off the cool box, long press
for three seconds until E1 displays, then
switch to E5 by pressing again. Under E5 mode, press or to select Celsius or Fahrenheit.
(*Factory setting is °C.)
• Reset: Switch off the cool box, long press for three seconds until E1 displays, under E1 mode, long
press at the same time for three seconds to reset it.
RECOMMENDED TEMPERATURES FOR COMMON FOOD:
6. *BATTERY OPERATION (*NOT INCLUDED)
Battery ON/OFF: A long press on the power button will switch the battery ON/OFF. When the battery is OFF,
a short press on the power button will show how much battery power is left.
Model: Arctic Frost Rechargeable Battery (590202) / FSAK-002
Capacity: 15600mAh/l 73Wh Rated Voltage: 11.1V
Charging Limited Voltage (DC): 12.6V Charging Limited
Current (DC): 3A
➀
Power Indicator (Green: charging; Blue: discharging)
➁
Battery Indicator (show current battery)
➂
Power Button
➃
DC Charging Port
Warning: do not disassemble the battery!
Charge in the cool box
(using dedicated adapter)
(Charging time≈8h)
Car cigarette lighter
DC 12/24V
(When the Input voltage>13.V,
charging time≈8h)
Solar (Not included)
DC 12 50V
(Connect to the "Solar" port of the cool box)
(When using 100W solar panel, charging time≈5h)
Charge in the cool box
(in standby model)
• Battery charging (for reference only):
UK: INSTRUCTION MANUALUK: INSTRUCTION MANUAL
Drinks Fruits Vegetable Ready-to-
eat food
Wine Ice cream Meat
5°C/41°F 5~8°C/41~46°F 3~10°C/37~50°F 4°C/39°F l0°C/50°F -l0°C/14°F -l8°C/0°F
USB LEFT COMPARTMENT RIGHT COMPARTMENT
TEMPERATURE CONTROL LED DISPLAY SET ON/OFF
INPUT
MODE
DC 12V DC 24V
CUT-OFF CUT-IN CUT-OFF CUT-IN
L 8.5V 10.9V 21.3V 22.7V
M 10.1V 11.4V 22.3V 23.7V
H 11.1V 12.4V 24.3V 25.7V
