Black plate (4,1)

Removing the front panel

1 Press the detach button to release the front

panel.

2 Push the front panel upward (M) and then pull

it toward (N) you.

3 Always store the detached front panel in a pro-

tective case or bag.

Re-attaching the front panel

1 Slide the front panel to the left.

2 Press the right side of the front panel until it is

firmly seated.

Forcing the front panel into place may result in

damage to the front panel or head unit.

Turning the unit on

1 Press SRC/OFF to turn the unit on.

Turning the unit off

1 Press and hold SRC/OFF until the unit turns

off.

Selecting a source

1 Press SRC/OFF to cycle between:

DIGITAL RADIO (digital audio broadcasting)

—RADIO—CD—USB/iPod—APP (application)

—AUX

! If a source other than DIGITAL RADIO is se-

lected, you can switch to DIGITAL RADIO by

pressing DAB.

! USB MTP displays while the MTP connection

is in use.

Adjusting the volume

1 Turn M.C. to adjust the volume.

Note

When this unit’s blue/white lead is connected to

the vehicle’s auto-antenna relay control termi-

nal, the vehicle’s antenna extends when this

unit’s source is turned on. To retract the anten-

na, turn the source off.

Frequently used menu

operations

Returning to the previous display

Returning to the previous list (the folder one level

higher)

1 Press

/DIMMER.

Returning to the ordinary display

Canceling the main menu

1 Press BAND/

.

Returning to the ordinary display from the list

1 Press BAND/

.

Digital Radio (Digital Audio

Broadcasting)

To receive DAB signals, connect a DAB antenna

(AN-DAB1) sold separately to the unit.

DAB stands for Digital Audio Broadcasting and

has the following features:

! High sound quality (nearly as high as for

CDs, although it may be reduced in some

cases in order to allow more services to be

broadcast)

! Interference-free reception

Note

Some stations perform broadcast testing.

Basic operations

Selecting a band

1 Press BAND/

until the desired band (D1, D2,

or D3) is displayed.

Manual tuning (step by step)

1 Press c or d.

Ensemble

Service

Primary Service Component

Press



.

Press



.

Primary Service Component

Secondary Service Component

Secondary Service Component

Service

Some individual services in an ensemble may be

further subdivided into Service Components. The

main Service Component is called the Primary

Service Component, and any auxiliary Service

Components are called Secondary Service Com-

ponents.

Seeking

1 Press and hold c or d, and then release.

Pausing

You can use the pause function to temporarily

stop listening to a DAB.

% Press DAB to pause or resume.

! This unit stores recent broadcasts to memory

automatically. The memory capacity of this

unit will vary depending on the bit rate of the

Service Component used. The approximate

memory capacity is five minutes for 192 kbps.

! If the duration that a selection is paused ex-

ceeds the length of the memory capacity,

playback will resume from the beginning of

the selection in memory.

This function is disabled while time shift is on.

For more details about time shift, refer to Listen-

ing to a recent broadcast (time shift) on page 5.

Storing and recalling stations

for each band

Using preset tuning buttons

1 To store: Press and hold down one of the

preset tuning buttons (1/

to 6/ ) until

the number stops flashing.

2 To recall: Press one of the preset tuning

buttons (1/

to 6/ ).

Switching the display

Selecting the desired text information

1 Press DISP to cycle between the following:

! SERVICE LABEL (service label or channel)

! BRDCST INFO (service label/PTY label/en-

semble label/channel and frequency)

! DYNAMIC LABEL (dynamic label)

! CLOCK (source name and clock)

Notes

! If the service label cannot be acquired in

SERVICE LABEL, the channel is displayed in-

stead. If the service label is detected, the

service label will be displayed.

! For more details about PTY list, refer to PTY

list on page 6.

Using this unit

4

Section

Using this unit

En

02

<QRD3198-B>4
