2
Max. detection range of an object measuring 1.7x0.5 m in natural night conditions (0.05 lux,
quarter moon). Detection range increases as the size of the objects under observation
and/or light intensity becomes greater.
For improvement purposes, design
of this product is subject to change.
PACKAGE CONTENTS
SPECIFICATIONS
Type of image intensifier tube
Magnification, x
Objective lens, mm
Resolution in the centre FOV, lines/mm, min
Angular field of view, degree
Max. detection range, m/yds*
Eyepiece adjustment, diopter
Eye relief, mm
Operating voltage, V
Tripod mount, inch
Av. operation time with 2 AAA batteries,
(IR off/on), h
Type of built-in IR illuminator / Wavelength, nm
Equivalent power, mW
Safety class for laser equipment according to
IEC 60825-1:2007
Output power for laser radiation,
not more than, mW
Operating temperature
Dimensions, mm/inch:
Length
Width
Height
Weight, kg/oz
*
Edge GS binoculars
Carrying case
User manual
Neck strap
Cleaning cloth
Warranty card
3
At the core of the Edge Night Vision Binoculars is the unique combination of
specially designed R-Contact optics and the CF-Super Image Intensifier Tube,
created specifically for each other such that they will not work with any other
system. The result of this exclusive technological development is the highest
edge-to-edge resolution performance ever seen in a budget consumer NV
product. The binocular is outfitted with new objective lenses that minimize
distortion on the edges of the field of view and increase sharpness and contrast of
the image.
The binoculars feature advanced design and improved operational
characteristics. The soft rubber eyecups conceal the light emission from the tube
thus permitting a user to stay unnoticed.
The binocular is equipped with a built-in LED (models 75096/75097) or laser IR
Illuminator (models 75098/75099) designed to operate in normal observation in
moonless cloudy conditions or in total darkness.
OVERVIEW
The Edge GS is equipped with a Weaver rail (models 75096/75097) that allows
additional accessories to be attached. The binocular is fully self-contained and
operates up to 50 hours on two AAA batteries.
Your binoculars are ideal for professional and amateur use, including:
Night observation in natural environment
Search and rescue
Night orienteering
Repair and maintenance of equipment
Hunting
Your night vision binocular is designed to provide many years of reliable service.
To ensure high performance you should adhere to the following rules:
PECULIARITIES OF USE
Damage to this device from failure to observe these warnings may void
the device's warranty!
The binoculars feature bright light protection system which prevents the
screen of the tube from burn-through in case of rapid change of illumination
level. If a bright object (such as flashlight, headlights, lamp etc.) shows up in
the field of view or if the unit is switched on without the caps on the lenses, the
image will grow darker. After the unit returns to its normal mode, green and
uniform image will be restored. Normal operation restores automatically within
a second unless the unit was switched off manually.
Your binoculars were designed to be self-contained. Do not open the body of
the unit or otherwise attempt to service this device. If such need arises return
the binocular for replacement or repair.
Protect the device from exposure to direct sunlight and extreme
temperatures.
Avoid dropping or otherwise shocking the device - it incorporates a
sophisticated optical system which could be damaged in extreme cases of
misuse.
Clean optical parts (lenses) with professional lens cleaning supplies
designed for use with multicoated optics.
75098
75099 75096
75097
SKU
Model
2.7x50L
3.5x50L 2.7x50
3.5x50
2.7
50
42
13
150/164
±4
12
3 (2xAAA)
¼
50 / 20
LED / 805
100
n/a
n/a
-20 °C~+40 °C /
203/8
122/4.8
65/2.6
0.85/30
3.5
50
42
11
170/186
±4
12
¼
50 / 20
100
n/a
n/a
233/9.1
122/4.8
71/2.6
0.85/30
2.7
50
42
13
200/219
±4
12
3 (2xAAA)
¼
50 / 20
Laser / 780
150
1
13
-4 °F~+104 °F
203/8
122/4.8
65/2.6
0.85/30
3.5
50
42
11
220/240
±4
12
¼
50 / 20
150
1
13
233/9.1
122/4.8
71/2.6
0.85/30
CF-Super / EP33-SF-U
