Mode d’emploi Whirlpool LWT1615Q Réfrigérateur combiné

Mode d’emploi

Use and

Care Manual

Electrical Shock Hazard

Connect the refrigerator ground to earth.

DO NOT modify the power cord. If it does not connect directly into the outlet,

contact a qualifi ed electrician to install the proper outlet.

DO NOT use extension cords with this refrigerator.

Consult a qualifi ed electrician to make sure that the refrigerator is effectively

connected to earth.

Failure to follow these instructions may bring risk of death or serious injury.

Install correctly

Before connecting the refrigerator

• Keep the refrigerator away from the effects of the weather.

• Connect the refrigerator to a suitable, grounded outlet.

• Do not put hot food in the refrigerator. Wait them to be at ambient temperature.

• Use the refrigerator only as specified in this manual.

• Make sure that the refrigerator is used only by competent persons.

Guidelines for food preservation

Fish or fresh seafood - Consume them in the same day of the purchase.

Chicken, minced beef, various meats (liver, etc.) - 1 to 2 days

Frozen meat, steaks / roasts - 3 to 5 days

Smoked meats - 7 to 10 days

Wrap the leftovers with plastic film, aluminum foil or store them in plastic containers with airtight lids.

Fizzy drinks should not be stored in low temperature compartments and some products with ice

particles should not be consumed too cold.

Freeze the meat if conservation for longer than the indicated periods is needed.

How to install the refrigerator

Follow the following steps before connecting the new refrigerator:

1. Remove the attachments from the package, including the internal ones.

2. Follow the following recommendations:

• Leave a minimum distance of 7.5 cm (3”) between the top of the refrigerator and the other

furnitur

e.

• Leave a minimum distance of 5 cm (2”) among the condenser, the refrigerator back and the wall.

• Leave a minimum distance of 1.25 cm (1/2”) on the side of the refrigerator for an easy installation.

• If the refrigerator is near one side wall leave additional space to allow opening of the door.

3. Level the refrigerator, depending on the model of your refrigerator, according to:

Style 1 - Casters with

leveling screws. To raise or

lower your refrigerator follow

the instructions in Figure 1.

Style 2 - Screws.

To raise or lower your

refrigerator follow the

instructions in Figure 2.

NOTES:

• This refrigerator has been developed to be used in locations where the ambient temperature

range can vary from a minimum of 55 °F (13 °C) and a maximum of 110 °F (43 °C). For optimal

performance, the proper temperatur

e (which reduces power consumption and ensures high

cooling) must be between 60 °F (15 °C) and 90 ° F (32 °C).

• The product should not be installed near heat sources (stove, heaters, etc.) or where it can be

exposed to direct sunlight.

ENGLISH

This Use and Care Manual applies to the following models:

LWT1615D, LWT1615Q, LWT1650A, LWT1840D, LWT1840Q, LWT1860A

STM W10885201 - Rev. A

This manual contains useful information. Read it carefully.

NP W10843050 - Rev. A

Manufactured by Acros Whirlpool Industries S.A. de C.V.

Antigua carretera a Roma Km 9

Col. Milagro

Apodaca N.L.

México, 66600

Tel. (01-81) 83 29 21 00

Rated current

Frequency

Rated voltage

6,0 A

60 Hz

115 V~

Electrical nominal characteristics

Important safety instructions

To reduce the risk of fire, electric shock, or injury when

using your refrigerator, follow these basic precautions.

■

Connect to a grounded outlet with 3-pin.

■

Do not remove the grounding of the

product.

■

Do not use adapters.

■

Do not use electric extension.

■

Remove the plug before cleaning or

repairing the product.

■

After cleaning or maintenance set all

components before connecting the

product.

■

If the power cord is damaged, it must be

replaced by the manufacturer or authorized

service or qualified person in order to avoid

the risk of accidents.

■

It is recommended to supervise children to

ensure that they do not play with the

product.

■

Remove the doors before discard your old

refrigerator.

■

Use cleaning materials that are not

flammable.

■

Keep flammable materials and vapors, such

as gasoline, away from the refrigerator.

■

Ask help to two or more people to move and

install the refrigerator.

■

This product is intended for household and

similar applications such as: kitchen areas in

shops, offices and other working

environments; farm houses and customers at

hotels, motels and other residential settings;

environments like hostels; Buffet and other

non-commercial applications.

■

Remove the plug before installing the Maker

Ice (for models that include the installation of

the Ice Maker).

■

This product is not intended for use by

persons (including children) with mental,

sensory or physical abilities reduced or lack

of experience and knowledge, unless they are

supervised or instructed by a person

responsible for their safety.

■

Don’t store explosive substances such as

aerosol cans with a flammable propellant

inside this product.

Quality Water Danger

Fill only with clean water.

Failure to follow this instruction can cause health problems.

Shelf for cans (some models)

Your new refrigerator has a shelf for cans on the door.

NOTE: Place only cans of 355 ml.

NOTE:

• For accuracy, check using a carpenter’s level, placed on the top of the

refrigerator or make sure that when opening and closing the door, the

refrigerator does not move.

• To facilitate the closure of your refrigerator door, slightly tilt the product

back.

4. Before connecting the refrigerator, let it rest for 2 to 3 hours, this will

allow the refrigerant gas and oil to stabilize before starting the cooling

process.

Turn the refrigerator on

A power supply properly

grounded at 115 V~ and 60 Hz, with fuse 15 or 20 A, according to

the voltage of your country is required.

SAVE THESE INSTRUCTIONS

Instructions for grounding

Grounding method

Your refrigerator has a power cord with a 3-prong plug.

To avoid the risk of electric shock, the power cord must be

connected to a proper and grounded outlet for 3-pin plugs,

according to the National Electrical Code and all local codes and

ordinances.

If the site does not have a proper and grounded outlet, consult a

qualified electrician to install it.

Do not modify the plug of your product.

Water dispenser (some models)

Your new refrigerator has an innovative water system on the door for

drawing

cold water without opening the refrigerator door, thus avoiding

excessive openings and hence reducing power consumption.

Water tank

The water tank must be manually filled and it is located inside the refrigerator compartment door.

The maximum reservoir capacity is 3.5 liters of water.

IMPORTANT:

• Clean the system before using it for the first time. To clean, fill the tank with clean water and

press the trigger dispenser with a large container or a jar, removing at least 1 liter of water.

Throw the water away. This process helps to clean and remove the air from the dispenser valve.

• Once the system is clean, wait for the water to cool to use the dispenser again.

• Exclusive use for clean water. Any other liquids such as drinks, milk, juices with pulp and seeds

may clog the valve and cause malfunctioning of the dispenser.

• The manufacturer is not liable for damage to the system if the tank is stocked with any other

liquid other than water.

NOTES:

• After 2 hours the water with gas could lose effervescence.

• Wash the tank before refill it. See item “Cleaning the dispenser”.

Fueling the water tank

To put water, turn and remove the small cap of the reservoir. Then fill with

a jar or bottle.

NOTE: For safety, the small cover can not be completely removed from

the reservoir.

IMPORTANT:

Always supply the water tank, when properly placed on the door.

WARNING: Fill only with clean water.

How to use the water dispenser:

1. Press a container (cup or pot) against the driver. Squeeze the trigger

holding it until the desired top up the needed water level.

2. After obtaining the desired water release the trigger, but do not remove

the container until the water has stopped running completely.

IMPORTANT:

Always remove water from the dispenser holding the container by hand.

Do not try to leave the container on the aperture of the dispenser.

NOTE: Water may have a strange taste, if the dispenser is not often used.

Cleaning the dispenser

1. Unhook the water tank, lifting it up and pulling it toward you to release

it from the refrigerator door (see figure 1).

2. Place the reservoir on a flat surface and disengage the cap

(see figure 2).

3. Disengage the valve by turning it to the left to see that the part is loose

(see figure 3). Remove and carefully wipe.

NOTE: Your refrigerator may have one of the two types of valves

illustrated.

4. Use a sponge or a soft cloth moistened with soapy water or mild soap.

Rinse thoroughly, making sure that there are no soap residue.

Dry with a clean, dry cloth.

NOTE: Do not use steel sponges or brushes to clean the tank, because

these materials can damage your product.

IMPORTANT:

Before placing the container on the door, make sure that:

• The valve is seated, ensure that the valve is in contact with the reservoir

hole.

• The sealing ring is placed correctly in the reservoir as shown in the

figure.

T

o place the tank on the refrigerator door:

1. Fit the valve on the reservoir turning it clockwise, replace the tank lid in place.

2. Replace the tank on the door tilting it slightly back, and snap it on the side door latches and

push it down until it clicks into place.

NOTE: Make sure the reservoir is properly seated in the door and that there is no possibility of

falling.

Fixed side Hinge side

Metal ring

Leveling screw

Screw

Figure 2

Style 2

Use a screwdriver to adjust

Caster

Leveling screw

Raise

Lower

Figure 1

Style 1

Figure 1

Figure 2

Figure 3

Wall grounded outlets for 3-pins plugs

Adequate and

grounded socket 3-pin

plugs

Power cable

Ground pin
