Quick Guide

EN

2

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the

dishwasher and reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it

After having carried out the verication and cleaning, turn o and turn

on the dishwasher and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: 15 and

On/O LED is blinking

rapidly

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLA-

TION).Check for siphoning into home sewage system, install air admit-

tance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Detergent leaks.

Depends on the liquid detergent used and can be

emphasized in case of delay option is activated.

Small leaks will not cause machine malfunction and can be avoided by

changing liquid detergent type or using tablets.

TROUBLESHOOTING

Please scan the QR code on your product in order to have more detailed information.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Bydefault the appliance washes dishes in all racks.

OPERATION INDICATOR -

A LED light projected on the oor indicates

that the dishwasher is working.

One of the following operating modes can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

NaturalDry

is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furniture.

LOADING THE RACKS

CAPACITY: 10 standard place-settings

UPPER RACK

(loading example

for the upper rack

Load delicate and light

dishes: glasses, cups, sa-

ucers, low salad bowls.

The upper rack has tip-

up supports which can

be used in a vertical

position when arrang-

ing tea/ dessert saucers

or in a lower position

to load bowls and food

containers.

FOLDABLE

FLAPS WITH

ADJUSTABLE

PO

SITION

LOWER RACK

(loading example

for the lower rack)

For pots, lids, plates, salad

bowls, cutlery etc. Large

plates and lids should ide-

ally be placed at the sides

to avoid interferences with

the spray arm.

The lower rack has tip-up

supports which can be

used in a vertical position

when arranging plates or

in a horizontal position

(lower) to load pans and

salad bowls easily

CUTLERY BASKET

The basket is equipped

with top grilles for im-

proved cutlery arrange-

ment. The cutlery basket

should be positioned

only at the front of the

lower rack.

Knives and other

utensils with sharp edges must be

placed in the cutlery basket with the

points facing downwards or they must

be positioned horizontally in the tip-

up compartments on the upper rack.

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

A

A

B

C

1 2 3

4

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in

aclockwise direction.

The lower spray arm may be

removed by pulling it upwards.

CARE AND MAINTENANCE

More information in the Daily Reference Guide on website.
