Daily Reference Guide

4

PROGRAMS TABLE

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: [email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Door is opened before the programm has been ended. This is to improve the drying eciency. Wait until the time has reached 00:00 to unload the dishwasher

**) Not all options can be used simultaneously.

***) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

Program

Programs description

Drying phase

NaturalDry

*)

Available

options

**)

Duration

of wash

program

(h: min)

***)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- program is suitable to clean normally soiled ta-

bleware, that for this use, it is the most ecient program

in terms of its combined energy and water consumption,

and that it is used to assess compliance with the EU Ecode-

sign legislation.

4:30 9.9 0.55

Auto Intensive 65° - Automatic pro-

gram for heavily soiled dishes and

pans.

Senses the level of

soiling on the dish-

es and adjusts the

program according-

ly. When the sensor

is detecting the soil

level an animation

appears in the dis-

play and the cycle

duration is updated.

2:25 - 3:10 15.5 - 24.5 1.30 - 1.70

Auto Mixed 55° - Automatic pro-

gram for normally soiled dishes with

dried food residues.

1:20 - 3:00 7.5 - 19.5 0.75 - 1.20

Auto Fast 50° - Automatic program

for normally and lightly soiled dish-

es. The everyday cycle that ensures

optimal cleaning and drying perfor-

mance in shorter time.

1:00 - 1:50 7.5 - 15.5 0.70 - 1.10

Rapid 45° - Program is recommended for limited amount

of lightly-soiled dishes with no dried food residues. Does

not include the drying phase.

-

0:30 - 0:40 10.0 - 12.0 0.55 - 0.65

Crystals 45° - Program for delicate items, which are more

sensitive to high temperatures, for example glasses and cups.

1:40 - 1:50 12.5 - 16.5 0.95 - 1.20

Prewash - Use to refresh crockery planned to be washed

later. No detergent is to be used with this program.

-

0:12 4.5 0.10

Self-Clean 65° -

Program to be used to perform mainte-

nance of the dishwasher, to be carried out only when the

dishwasher is EMPTY using specic detergents designed

for dishwasher maintenance.

-

-

1:15 11.0 1.10

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

1. Select the program and any desired options. Press the DELAY button

(repeatedly) to delay the start of the program. Adjustable from 0:30 to 24

hours. Once the 24 hours setting is reached, press the DELAY another time

to deactivate the DELAY function.

2. Press the START/Pause button and close the door within 4 sec. the timer

will begin counting down.

3. Once this time has elapsed, the indicator light switches o and the program

begins automatically.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is aconvection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying perfor-

mance every day. Door opens at the temperature that is safe to your kitch-

en furniture, thus door will not be opened when the option of SANI RINSE

is on. As additional steam protection, special designed protection foil is

added together with the dishwasher.

To see how to mount protection foil please refer to the INSTALLATION

GUIDE. This feature is active by default, but it is possible to deactivate it in

the “SETTINGS MENU”

SILENT - Suitable for night-time operation of the appliance. This option

can be used to limit noise emission during wash phases. It will increase

cycle time depending on base cycle selection.

SANI RINSE - This option can be used to sanitize washed dishes. It will

increase the nal rinse temperature and add antibacterial wash to the

selected program. Ideal to clean crockery and feeding bottles. The dishwasher

door must be kept shut for the entire duration of the program in order to

guarantee reduction of germs. WARNING: the crockery and plates could

be extremely hot at the end of the cycle.

TURBO - Thanks to the Turbo option you can reduce time up to 40%

depending on the selected based program. Energy and water

consumption are increased.

SENSING - When the sensor is detecting the soil level an animation

appears in the display (around 20 min.) and the cycle duration is

updated. SENSING is for the level of soiling on the dishes and is

present for all cycles (excepting Eco) adjusting the program accordingly.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

OPTIONS AND FUNCTIONS
