2

EN

1. CHECK WATER CONNECTION

Check that the dishwasher is connected to the water supply and that

the tap is open.

2. SWITCH ON THE DISHWASHER

Open the door and press the ON/OFF button.

3. LOAD THE RACKS (see LOADING THE RACKS).

4. FILL THE DETERGENT DISPENSER

5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE

Select the most appropriate program in accordance with the type of

crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing

the PREVIOUS/NEXT buttons.

Select the desired options (see OPTIONS AND FUNCTIONS). Not all op-

tions are compatible with all programs.

6. START

Start the wash cycle by pressing START/Pause button (led is lit) and

closing the door within 4 sec. When the program starts you hear asingle

beep. If the door was not closed within 4sec., the alarm sound will be

played. In this case, open the door, press START/Pause button and close

the door again within 4 sec.

7. END OF WASH CYCLE

The end of the wash cycle is indicated by sound and the display shows

END. Open the door and switch o the appliance by pressing the

ON/OFF button.

Wait for afew minutes before removing the crockery - to avoid burns.

Unload the racks, beginning with the lower one.

MODIFYING ARUNNING PROGRAM

If awrong program was selected, it is possible to change it, provided that it

has only just begun. RESET the machine: press and hold the ON/OFF but-

ton for more than 3. sec., and the machine will switch o. The dashboard

will show “0:01”. Close the door and wait until drain cycle ends (around 1

minute). Open the door and switch the machine back on using the ON/OFF

button and select the new wash cycle and any desired options. Start the cy-

cle by pressing the START/Pause button and closing the door within 4 sec.

ADDING EXTRA CROCKERY

Without switching o the machine, open the door rst slightly to avoid wa-

ter splashing out (START/Pause led starts blinking) (Caution!: Hot steam!)

and place the crockery inside the dishwasher. Press the START/Pause but-

ton and close the door within 4 sec., the cycle will resume from the point at

which it was interrupted.

ACCIDENTAL INTERRUPTIONS

If the door is opened during the wash cycle, or if there is apower cut, the

cycle stops. ONLY IF YOU PRESS the START/Pause button and close the

door within 4 sec., the cycle will resume from the point at which it was

interrupted.

WATER MANAGEMENT SYSTEM

This dishwasher allows the storage of up to 3.2 litres of fresh water using

it in the selected programs. Water is stored in adedicated tank and will be

used in the subsequently selected programs. It is recommended to per-

form the Self-Clean cycle (see PROGRAMS TABLE) periodically.

TIPS

Before loading the baskets, remove all food residues from the crockery and

empty the glasses. You do not need to rinse beforehand under running

water.

Arrange the crockery so that it is held in place rmly and does not tip over;

and arrange the containers with the openings facing downwards and the

concave/convex parts placed obliquely, thus allowing the water to reach

every surface and ow freely.

Warning: lids, handles, trays and frying pans should not prevent the spray-

er arms from rotating.

Place any small items in the cutlery basket.

Very soiled dishes and pans should be placed in the lower basket because

in this sector the water sprays are stronger and allow ahigher washing per-

formance.

After loading the appliance, make sure that the sprayer arms can rotate

freely.

UNSUITABLE CROCKERY

• Wooden crockery and cutlery.

• Delicately decorated glasses, artistic handicrafts and antique crockery.

Their decorations are not resistant.

• Parts in synthetic material which do not withstand high temperatures.

• Copper and tin crockery.

• Crockery soiled with ash, wax, lubricating grease or ink.

The colours of glass decorations and aluminium/silver pieces can change

and fade during the washing process. Some types of glass (e.g. crystal ob-

jects) can become opaque after anumber of wash cycles too.

DAMAGE TO GLASS AND CROCKERY

• Only use glasses and porcelain guaranteed by the manufacturer as dish-

washer safe.

• Use adelicate detergent suitable for crockery

• Collect glasses and cutlery from the dishwasher as soon as the wash cy-

cle is over.

TIPS ON ENERGY SAVING

• When the household dishwasher is used according to the manufacturer’s

instructions, washing tableware in a dishwasher usually consumes

less energy and water than hand dishwashing.

• In order to maximize dishwasher eciency, it is recommended to initi-

ate the wash cycle once the dishwasher is fully loaded. Loading the

household dishwasher up to the capacity indicated by the manufacturer

will contribute to energy and water savings. Information on the correct

loading of tableware can be found in the Loading chapter. In case of par-

tial loading, it is recommended to use adedicated wash options if avail-

able (Half load/ Zone Wash/ Multizone), lling up only selected racks. In-

correct loading or overloading of the dishwasher may increase resources

usage (such as water, energy and time, as well as increase noise level),

reducing cleaning and drying performance.

• Manual pre-rinsing of tableware items leads to increased water and ener-

gy consumption and is not recommended.

HYGIENE

To avoid odour and sediment which can be accumulated in the dishwash-

er please run ahigh-temperature program at least once amonth. Use

ateaspoon of detergent and run it without loading to clean your appliance.

MOVING OR SERVICING THE DISHWASHER

This dishwasher includes awater tank that may remain full of water af-

ter the cycle ends (water can leak out if / when the dishwasher is tipped).

Note: Before servicing or moving the dishwasher, run the Self-Clean cycle

to drain the water tank.

RESISTANCE TO FROST

If the appliance is placed in surroundings exposed to the risk of frost, it

must be drained completely. Turn o the water tap, remove the inlet and

outlet hoses, and let all the water drain away. Make sure that the water

softener is full of dissolved regeneration salt in the salt container, to

protect the appliance from temperatures of up to -20°C.

If the appliance was stored in frost conditions the appliance must remain at

an ambient temperature of min. 5°C for at least 24 hours before the rst run.

ADVICE AND TIPS

DAILY USE

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the open-

ing device C. Introduce the detergent into the

dry dispenser D only. Place the amount of deter-

gent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser D, there are indica-

tions to help the detergent dosing.

D

C

2. Remove detergent residues from the edges of the dispenser and close

the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program. Usage of detergent not designed for dishwashers

may cause malfunction or damage to the appliance.
