1. Safety precautions

s Before operating the unit, make sure you read all the “Safety

precautions”.

s “Safety precautions” lists important points about safety.

Please be sure to follow them.

Symbols used in the text

Warning:

Describes precautions that should be observed to avoid the risk of injury or

death to the user.

Caution:

Describes precautions that should be observed to prevent damage to the unit.

Symbols used in the illustrations

: Indicates an action that must be avoided.

: Indicates that important instructions must be followed.

: Indicates a part which must be grounded.

: Indicates that caution should be taken with rotating parts. (This symbol is

displayed on the main unit label.) <Color: yellow>

: Beware of electric shock. (This symbol is displayed on the main unit label.)

<Color: yellow>

Warning:

Carefully read the labels affixed to the main unit.

1.1. Installation

s After you have read this manual, keep it and the Installation Manual in a

safe place for easy reference whenever a question arises. If the unit is

going to be operated by another person, make sure that this manual is

given to him or her.

Warning:

• The unit should not be installed by the user. Ask the dealer or an author-

ized company to install the unit. If the unit is installed improperly, water

leakage, electric shock or fire may result.

• Use only accessories authorized by Mitsubishi Electric and ask your

dealer or an authorized company to install them. If accessories are in-

stalled improperly, water leakage, electric shock or fire may result.

• The Installation Manual details the suggested installation method. Any

structural alteration necessary for installation must comply with local

building code requirements.

• Never repair the unit or transfer it to another site by yourself. If repair is

performed improperly, water leakage, electric shock or fire may result. If

you need to have the unit repaired or moved, consult your dealer.

• Keep the electric parts away from water (washing water) etc.

• It might result in electric shock, catching fire or smoke.

Note1:

When washing the Heat Exchanger and Drain Pan, ensure the Con-

trol Box, Motor and LEV remain dry, using a water proof covering.

Note2: Never drain the washing water for the Drain Pan and the Heat

Exchanger using the Drain Pump. Drain separately.

• The appliance is not intended for use by young children or infirm per-

sons without supervision.

• Young children should be supervised to ensure that they do not play

with the appliance.

• Do not use a leak detection additive.

1) Outdoor unit

Warning:

• The outdoor unit must be installed on a stable, level surface, in a place

where there is no accumulation of snow, leaves or rubbish.

• Do not stand on, or place any items on the unit. You may fall down or the

item may fall, causing injury.

Caution:

The outdoor unit should be installed in a location where air and noise emit-

ted by the unit will not disturb the neighbours.

2) Indoor unit

Warning:

The indoor unit should be securely installed. If the unit is loosely mounted, it

may fall, causing injury.

3) Remote controller

Warning:

The remote controller should be installed in such a way that children cannot

play with it.

4) Drain hose

Caution:

Make sure that the drain hose is installed so that drainage can go ahead

smoothly. Incorrect installation may result in water leakage, causing dam-

age to furniture.

5) Power line, fuse or circuit breaker

Warning:

• Make sure that the unit is powered by a dedicated supply. Other appli-

ances connected to the same supply could cause an overload.

• Make sure that there is a main power switch.

• Be sure to adhere to the unit’s voltage and fuse or circuit breaker ratings.

Never use a piece of wire or a fuse with a higher rating than the one

specified.

6) Grounding

Caution:

• The unit must be properly grounded. Never connect the grounding wire

to a gas pipe, water pipe, lightning conductor or telephone grounding

wire. If the unit is not grounded properly, electric shock may result.

• Check frequently that the ground wire from the outdoor unit is properly

connected to both the unit’s ground terminal and the grounding electrode.

1.2. During operation

Caution:

• Do not use any sharp object to push the buttons, as this may damage the

remote controller.

• Do not twist or tug on the remote controller cord as this may damage the

remote controller and cause malfunction.

• Never remove the upper case of the remote controller. It is dangerous to

remove the upper case of the remote controller and touch the printed

circuit boards inside. Doing so can result in fire and failure.

• Never wipe the remote controller with benzene, thinner, chemical rags,

etc. Doing so can result in discoloration and failure. To remove heavy

stains, soak a cloth in neutral detergent mixed with water, wring it out

thoroughly, wipe the stains off, and wipe again with a dry cloth.

• Never block or cover the indoor or outdoor unit’s intakes or outlets. Tall

items of furniture underneath the indoor unit, or bulky items such as

large boxes placed close to the outdoor unit will reduce the unit’s effi-

ciency.

Warning:

• Do not splash water over the unit and do not touch the unit with wet

hands. An electric shock may result.

• Do not spray combustible gas close to the unit. Fire may result.

• Do not place a gas heater or any other open-flame appliance where it will

be exposed to the air discharged from the unit. Incomplete combustion

may result.

Contents

1. Safety precautions ...................................................................................... 4

1.1. Installation ................................................................................. 4

1.2. During operation ........................................................................ 4

1.3. Disposing of the unit .................................................................. 5

2. Names and functions of various parts ........................................................ 5

3. How to operate ........................................................................................... 5

3.1. ON/OFF ..................................................................................... 5

3.2. Selecting operation .................................................................... 5

3.3. Room temperature adjustment .................................................. 6

3.4. Fan speed adjustment ............................................................... 6

3.5. Ventilation .................................................................................. 6

3.6. Others ........................................................................................ 6

4. The smart way to use ................................................................................. 7

5. Caring for the machine ............................................................................... 7

6. Troubleshooting ........................................................................................... 8

7. Installation, transferring works, and checking ............................................. 9

8. Specifications .............................................................................................. 9
