Mode d’emploi

5

I

GBDFEINLPGRRUTRGBGBGBGBGB

Warning:

• Do not remove the front panel or the fan guard from the outdoor unit

when it is running. You could be injured if you touch rotating, hot or high-

voltage parts.

• Never insert fingers, sticks etc. into the intakes or outlets, otherwise in-

jury may result, since the fan inside the unit rotates at high speed. Exer-

cise particular care when children are present.

• If you detect odd smells, stop using the unit, turn off the power switch

and consult your dealer. Otherwise, a breakdown, electric shock or fire

may result.

• When you notice exceptionally abnormal noise or vibration, stop opera-

tion, turn off the power switch, and contact your dealer.

• Do not over-cool. The most suitable inside temperature is one that is

within 5

°C [41 °F] of the outside temperature.

• Do not leave handicapped people or infants sitting or standing in the path

of the airflow from the air-conditioner. This could cause health problems.

Caution:

• Do not direct the airflow at plants or caged pets.

• Ventilate the room frequently. If the unit is operated continuously in a

closed room for a long period of time, the air will become stale.

In case of failure

Warning:

• Never remodel the air conditioner. Consult your dealer for any repair or serv-

ice. Improper repair work can result in water leakage, electric shock, fire, etc.

• If the remote controller displays an error indication, the air conditioner

does not run, or there is any abnormality, stop operation and contact

your dealer. Leaving the unit as it is under such conditions can result in

fire or failure.

• If the power breaker is frequently activated, get in touch with your dealer.

Leaving it as it is can result in fire or failure.

• If the refrigeration gas blows out or leaks, stop the operation of the air

conditioner, thoroughly ventilate the room, and contact your dealer. Leav-

ing the unit as it is can result in accidents due to oxygen deficiency.

When the air conditioner is not to be used for a long

time

• If the air conditioner is not to be used for a long time due to a seasonal

change, etc., run it for 4 - 5 hours with the air blowing until the inside is

completely dry. Failing to do so can result in the growth of unhygienic,

unhealthy mold in scattered areas throughout the room.

• When it is not to be used for an extended time, keep the [power supply]

turned OFF.

If the power supply is kept on, several watts or several tens of watts will

be wasted. Also, the accumulation of dust, etc., can result in fire.

• Keep the power switched ON for more than 12 hours before starting op-

eration. Do not turn the power supply OFF during seasons of heavy use.

Doing so can result in failure.

1.3. Disposing of the unit

Warning:

When you need to dispose of the unit, consult your dealer. If pipes are re-

moved incorrectly, refrigerant (fluorocarbon gas) may blow out and come

into contact with your skin, causing injury. Releasing refrigerant into the

atmosphere also damages the environment.

2. Names and functions of various parts

Attachment and detachment of filter

[Fig. A] (P.3)

3. How to operate

Before starting operation

• Start running after the “PLEASE WAIT” display has disappeared. The “PLEASE

WAIT” display briefly appears on the room temperature display (max. 3 min-

utes) when the power is turned on and after a power failure. This does not

indicate any failure of the air-conditioner.

• The choice of indoor unit operation mode is limited by the operation status of

the outdoor unit to which a given indoor unit is connected. If an outdoor unit

and some of the indoor units that are connected to the outdoor units are al-

ready operating in the cooling mode, for example, only the cooling mode is

available for the rest of the units in the same group. If a different mode is re-

quested, the symbol that corresponds to the requested mode will blink, notify-

ing the user that the mode is currently unavailable. The same is true for the dry

and heating mode. This restriction, however, does not apply to the models that

support a simultaneous cooling/heating function.

• The outdoor units stop when all the indoor units connected to the counterpart

outdoor units stop.

• During heating operation, even if the indoor unit is set to operation while the

outdoor unit is in defrosting operation, operation starts after the defrosting op-

eration of the outdoor unit has ended.

3.1. ON/OFF

Start an operation

1. Press the B [ON/OFF] button

P Operation lamp lights up and operation starts.

Stop an operation

1. Press the B [ON/OFF] button again

Operation lamp goes off and operation stops.

• Once the Buttons have been set, pressing of the [ON/OFF] Button only can

repeat the same operation thereafter.

• During operation, the operation lamp above the [ON/OFF] button lights up.

Caution:

Even if the [ON/OFF] Button is pressed immediately after the operation is

once stopped, operation is not restarted for about 3 minutes. This function

protects the machine. It automatically starts operation after the lapse of

approximately 3 minutes.

3.2. Selecting operation

When selecting operation

1. Press the 3 [Mode (Back)] Button

Consecutive press of the selecting operation Button switches the operation

over to E “

COOL”, “ DRY”, “ FAN”, (“ AUTO”), and (“ HEAT”). For

the contents of operation, check the display.

For cooling

Press the 3 [Mode (Back)] Button and bring up the “ COOL” display.

For dry

Press the 3 [Mode (Back)] Button and bring up the “ DRY” display.

• The indoor fan turns to the low-speed operation, disabling the change of fan

speed.

• Dry operation cannot be carried out at room temperature of less than 18 °C

[65 °F].

Caution:

• In removing the filter, precautions must be taken to protect your eyes

from dust. Also, if you have to climb up on a stool to do the job, be careful

not to fall.

• Turn off the power supply when the filter is changed.

ON/OFF

CHECK

CLEAR

MENU

ON/OFF

TEST

TEMP.

CLOCK

OPERATION

BACK DAY

MONITOR/SET

1

E

2

3

68

B

P

7

FILTER

ERROR CODE

TIME

ON

OFF

Hr

AFTER

SUN MON TUE WED THU FRI SAT

TIMER

AFTER

ONLY 1Hr.

˚C˚F

WEEKLY

SIMPLE

AUTO OFF

FILTER

FUNCTION

˚C˚F

KB79K384H01_en.p65 08.1.28, 2:16 PM5
